REDEL MOF.M06 MP Series 6 Pin Female Crimp Module
Press and move to zoom
Mouse over image to zoom
Click to Enlarge

Description

The REDEL MOF.M06.ZLM1 is a 6 pin crimp version female module.

Specs

Electrical Configuration

Contact Termination Low voltage
Crimp
Insert configuration value
MO/M06 - 6 Low Voltage
Insulator
L: PEEK (UL 94 / V-0/1.5)
Rated current
4 A
Vtest (contact-contact)
1700 V (DC)
Vtest (contact-shell)
n.a.
Max. Stranded Conductor
0.382 mm^2 (AWG 22)
Air clearance
1.07 mm
Creepage distance
1.07 mm
Bucket Dia.
0.8
Contact Dia.
0.7
Number of contacts Low Voltage
6
Wire Size/AWG
26 - 22
Gender
Standard

Form & Material

Shell style / Model id
MOF - Module single Low Voltage with Female crimp contacts
Weight
2.11 g

Environment

Technical domain
Energy and Industrial, Medical, Test and Measurement
Environmental sealing (IP rating)
IP50

REDEL MOF.M06 MP Series 6 Pin Female Crimp Module

LEMO Connectors

Product code : RED.MOFM06ZLM1

$ 47.52
  • Availability: Out of Stock Call for a delivery estimate
